Omron F3SJ-A series User Manual

14
Chapter1 Ratings
F3SJ-A
User’s Manual
Overview and Specifications
For series connections, use the calculations below.
When 2 sets are series-connected:
•Response time (ON to OFF) :Response time of primary sensor + Response time of secondary sensor
1 -1 (ms)
•Response time (OFF to ON) :Response time (ON to OFF) x 4 (ms)
When 3 sets are series-connected:
•Response time (ON to OFF) :Response time of primary sensor + Response time of secondary sensor
2 + Response time of 3rd unit - 5 (ms)
•Response time (OFF to ON) : Smaller value of response time (ON to OFF) x 5 (ms) or 200ms
Designation of F3SJ in series connection: p.52
F3SJ-A2015P20-TS - 134 beams 20.0ms 80ms
F3SJ-A2030P20-TS - 135 beams 20.0ms 80ms
F3SJ-A2045P20-TS - 136 beams 20.0ms 80ms
F3SJ-A2060P20-TS - 137 beams 20.0ms 80ms
F3SJ-A2075P20-TS - 138 beams 20.0ms 80ms
F3SJ-A2090P20-TS - 139 beams 20.0ms 80ms
F3SJ-A2105P20-TS - 140 beams 20.0ms 80ms
F3SJ-A2120P20-TS - 141 beams 20.0ms 80ms
F3SJ-A2135P20-TS - 142 beams 20.0ms 80ms
F3SJ-A2150P20-TS - 143 beams 20.0ms 80ms
F3SJ-A2165P20-TS - 144 beams 20.0ms 80ms
F3SJ-A2180P20-TS - 145 beams 22.5ms 90ms
F3SJ-A2195P20-TS - 146 beams 22.5ms 90ms
F3SJ-A2210P20-TS - 147 beams 22.5ms 90ms
F3SJ-A2225P20-TS - 148 beams 22.5ms 90ms
F3SJ-A2240P20-TS - 149 beams 22.5ms 90ms
F3SJ-A2255P20-TS - 150 beams 22.5ms 90ms
F3SJ-A2270P20-TS - 151 beams 22.5ms 90ms
F3SJ-A2285P20-TS - 152 beams 22.5ms 90ms
F3SJ-A2300P20-TS - 153 beams 22.5ms 90ms
F3SJ-A2315P20-TS - 154 beams 22.5ms 90ms
F3SJ-A2330P20-TS - 155 beams 22.5ms 90ms
F3SJ-A2345P20-TS - 156 beams 22.5ms 90ms
F3SJ-A2360P20-TS - 157 beams 22.5ms 90ms
F3SJ-A2375P20-TS - 158 beams 22.5ms 90ms
F3SJ-A2390P20-TS - 159 beams 22.5ms 90ms
F3SJ-A2405P20-TS - 160 beams 22.5ms 90ms
F3SJ-A2420P20-TS - 161 beams 22.5ms 90ms
F3SJ-A2435P20-TS - 162 beams 22.5ms 90ms
F3SJ-A2450P20-TS - 163 beams 22.5ms 90ms
F3SJ-A2465P20-TS - 164 beams 22.5ms 90ms
F3SJ-A2480P20-TS - 165 beams 22.5ms 90ms
F3SJ-A2495P20-TS - 166 beams 22.5ms 90ms
F3SJ-AP20-TS F3SJ-AP25-TS Number of beams
Response time
(ON to OFF)
Response time
(OFF to ON)
