Omron F3SJ-A series User Manual

11
F3SJ-A
User’s Manual
Chapter1 Ratings
Overview and Specifications
E
 Model Name List/Response Times
Weight (packaged) - F3SJ-AP20-TS/F3SJ-AP25-TS
Weight (g)=(protective height) x 1.5+ α
The values for α are as follows:
When protective height is between 245 and 596mm, α=1100
When protective height is between 600 and 1130mm, α=1500
When protective height is between 1136 and 1658mm, α=2000
When protective height is between 1660 and 2180mm, α=2400
When protective height is between 2195 and 2500mm, α=2600
Accessories Test rod, instruction sheet, top and bottom mounting brackets, intermediate mounting brackets
(*), error mode label, user’s manual (CD-ROM)
* The number of intermediate mounting brackets depends on the total length of the F3SJ.
- F3SJ total length is from 600 to 1,130mm: 1 set for each the emitter and receiver is included
- F3SJ total length is from 1136 to 1,658mm: 2 sets for each the emitter and receiver are
included
- F3SJ total length is from 1660 to 2,180mm: 3 sets for each the emitter and receiver are
included
- F3SJ total length is from 2195 to 2500mm: 4 sets for each the emitter and receiver are
included
Applicable standards IEC61496-1, EN61496-1, UL61496-1 Type 4ESPE (Electro-Sensitive Protective Equipment)
IEC61496-2, prEN61496-2, UL61496-2 Type 4AOPD (Active Opto-electronic Protective
Devices)
IEC61508, EN61508 SIL3
F3SJ-AP20-TS F3SJ-AP25-TS Number of beams
Response time
(ON to OFF)
Response time
(OFF to ON)
- F3SJ-A0260P25-TS 13 beams 10ms 40ms
- F3SJ-A0280P25-TS 14 beams 10ms 40ms
- F3SJ-A0300P25-TS 15 beams 10ms 40ms
F3SJ-A0245P20-TS F3SJ-A0320P25-TS 16 beams 10ms 40ms
F3SJ-A0260P20-TS F3SJ-A0340P25-TS 17 beams 11ms 44ms
F3SJ-A0275P20-TS F3SJ-A0360P25-TS 18 beams 11ms 44ms
F3SJ-A0290P20-TS F3SJ-A0380P25-TS 19 beams 11ms 44ms
F3SJ-A0305P20-TS F3SJ-A0400P25-TS 20 beams 11ms 44ms
F3SJ-A0320P20-TS F3SJ-A0420P25-TS 21 beams 11ms 44ms
F3SJ-A0335P20-TS F3SJ-A0440P25-TS 22 beams 11ms 44ms
F3SJ-A0350P20-TS F3SJ-A0460P25-TS 23 beams 11ms 44ms
F3SJ-A0365P20-TS F3SJ-A0480P25-TS 24 beams 11ms 44ms
F3SJ-A0380P20-TS F3SJ-A0500P25-TS 25 beams 11ms 44ms
F3SJ-A0395P20-TS F3SJ-A0520P25-TS 26 beams 11ms 44ms
F3SJ-A0410P20-TS F3SJ-A0540P25-TS 27 beams 11ms 44ms
F3SJ-A0425P20-TS F3SJ-A0560P25-TS 28 beams 11ms 44ms
F3SJ-A0440P20-TS F3SJ-A0580P25-TS 29 beams 11ms 44ms
F3SJ-A0455P20-TS F3SJ-A0600P25-TS 30 beams 12ms 48ms
F3SJ-A0470P20-TS F3SJ-A0620P25-TS 31 beams 12ms 48ms
F3SJ-A0485P20-TS F3SJ-A0640P25-TS 32 beams 12ms 48ms
F3SJ-A0500P20-TS F3SJ-A0660P25-TS 33 beams 12ms 48ms
F3SJ-A0515P20-TS F3SJ-A0680P25-TS 34 beams 12ms 48ms
F3SJ-A0530P20-TS F3SJ-A0700P25-TS 35 beams 12ms 48ms
F3SJ-A0545P20-TS F3SJ-A0720P25-TS 36 beams 12ms 48ms
F3SJ-A0560P20-TS F3SJ-A0740P25-TS 37 beams 12ms 48ms
F3SJ-AP20-TS F3SJ-AP25-TS
