9
F3SJ-A
User’s Manual
Chapter1 Ratings
Overview and Specifications
E
Ratings

Ratings/Specifications
In the model names in this table, the  contain the 4-digit number indicating the protective height
(mm).
F3SJ-AP20-TS F3SJ-AP25-TS
Detection capability Opaque objects Opaque objects
Diameter 20mm Diameter 25mm
Beam gap 15mm 20mm
Number of beams 16 to 166 13 to 125
Protective height 245 to 2,495mm 260 to 2,500mm
Lens diameter Diameter 5mm
Operating range 0.2 to 9m (for protective height up to 1649 mm)
0.2 to 7m (for protective height 1655 mm or greater)
Response time ON to OFF: 10ms to 22.5ms max., OFF to ON: 40ms to 90ms max. (when incidence is stable).
Refer to p.11 for details.
Startup waiting time 2s max. (2.2s max in case of series connection)
Power supply voltage(Vs) 24VDC ± 20% (ripple p-p10% max.)
Current consumption
(no load)
Emitter
Up to 50 beams: 76 mA max., 51 to 100 beams: 106 mA max., 101 to 150 beams: 130 mA max.,
151 to 166 beams: 153 mA max.
Receiver Up to 50 beams: 68 mA max., 51 to 100 beams: 90 mA max., 101 to 150 beams: 111 mA max.,
151 to 166 beams: 128 mA max.
Light source Infrared LED (870nm wavelength)
Effective aperture angle (EAA) Within ±2.5 ° for the emitter and receiver at a detection distance of at least 3 m according to
IEC61496-2
Safety outputs(OSSD) PNP transistor outputs x 2, Load current 300mA max, Residual voltage 2V max. (except for
voltage drop due to cable extension), Maximum capacity load 2.2
µF, leakage current 1 mA
max. (This may be different from previously used logic (ON/OFF) because safety circuit is
used.)
Auxiliary output 1 (Non-safety output) PNP transistor output x 1, Load current 300mA max., Residual voltage 2V max. (except for
voltage drop due to cable extension), leakage current 1mA max.
External indicator output (Non-safety
output)
Connectable external indicator
- Incandescent lamp : 24VDC, 3 to 7W
- LED lamp : Load current 10 to 300mA max.
Leakage current 1mA max.
(An indicator cable F39-JJ3N or F39-A01P-PAC is required when using an external
indicator.)
Output operation mode Safety outputs : ON when receiving light
Auxiliary output 1 : Reverse output of safety output
External indicator output 1: Reverse output of safety output (for basic system), ON during
muting/override (for muting system)
External indicator output 2: ON in lockout (for basic system), ON during muting/override (for
muting system)
Input voltage Test input, reset input, and muting input are all:
ON voltage: 9 to 24Vs (sink current 3mA max.)
OFF voltage: 0 to 1.5V , or open
External device monitoring input is:
ON voltage: 9 to 24Vs (sink current 5mA max.)
OFF voltage: 0 to 1.5V , or open
