Omron F3SJ-A series User Manual

78
Chapter3 Dimensions
F3SJ-A
User’s Manual
Wiring/Installation
Dimensions A to D
A C+108
BC+76
C 4-digit number of the model name (protective height)
DC+44
13.5
5.5
20
dia. 6.5
16
16
2
8
dia. 9
DBA
BB
32
22
32
dia. 60.5
8
2
2-M8
2-M6
20
20
8
2
4-M5
Side mounting
Hole size for mounting
(Unit: mm)
Using M5 Using M6 and M8
Material: Acrylic resin, nitrile rubber, stainless steel
2-Mounting brackets
(F39-EJ-S) *1
C
(Protective
height)
*1 Mounting Bracket (F39-EJ-S) is not included.
