Processing Items That Supports Automatic Parallelization

The following table lists the processing items that support the automatic parallelization.

Processing item

Par-

allel-

ize

proc

ess-

ing

Processing item

Par-

allel-

ize

proc

ess-

ing

Processing item

Par-

allel-

ize

proc

ess-

ing

Camera Image Input - Back Ground Suppression - Transfer Position Data -

Camera Image Input FH - Brightness Correct Filter - Calc Axis Move -

Camera Image Input FHV - Color Gray Filter - Calc Axis Move by Multi-

point

Camera Image Input HDR - Extract Color Filter - Detection Point -

Camera Image Input HDR

Lite

- Anti-Color Shading - Camera Calibration -

Camera Switching - Stripes Removal Filter II - Data Save -

Measurement Image

Switching

- Polar Transformation - Conditional Branch -

Search OK Trapezoidal Correction - End -

Flexible Search OK Machine Simulator - DI Branch -

Sensitive Search OK Image Subtraction - Control Flow Normal -

ECM Search OK Advanced Filter - Control Flow PLC Link -

EC Circle Search OK Panorama - Control Flow Parallel -

EC Corner OK Calculation - Control Flow Fieldbus -

EC Cross OK Line Regression - Selective Branch -

Shape Search II OK Circle Regression - Data Output -

Classification OK Precise Calibration - Parallel Data Output -

Edge Position OK User Data - Parallel Judgement Output -

Edge Pitch OK Set Unit Data - Fieldbus Data Output -

Scan Edge Position OK Get Unit Data - Result Display -

Scan Edge Width OK Set Unit Figure - Display Image File -

Circular Scan Edge Posi-

tion

OK Get Unit Figure - Display Last NG Image -

Circular Scan Edge Width OK Trend Monitor - OCR OK

Color Data OK Image Logging - OCR User Dictionary -

Gravity and Area OK Image Conversion Logging - Conveyor Calibration -

Labeling OK Data Logging - Conveyor Panorama Dis-

play

Label Data - Elapsed Time - Photometric Stereo Image

Input

Defect OK Wait - Display image hold -

Precise Defect OK Focus OK Conditional execution (If) -

Fine Matching OK Iris OK Conditional execution

(Else)

Character Inspection OK Unit Macro - Loop -

Date Verification - Unit Calculation Macro - Loop suspension -

Model Dictionary - Parallelize - Scene -

2D Codes - Parallelize Task - Select execution (Select) -

Circle Angle OK Statistics - Select execution (Case) -

4 Setting the Controller

4 - 35

FH/FHV Series Vision System User’s Manual (Z365-E1)

4-4 Setting Operation Mode [Startup Settings]

4-4-2 Parallel Processing
