Omron FHV7 series User Manual

Processing item
Par-
allel-
ize
proc
ess-
ing
Processing item
Par-
allel-
ize
proc
ess-
ing
Processing item
Par-
allel-
ize
proc
ess-
ing
Shape Search III - Calibration Data Reference - System information -
Intersection OK Position Data Calculation - Manual Position Setting -
Barcode OK Stage Data - 2DCode II -
Glue Bead Inspection OK Robot Data - Result output (I / O) -
Position Compensation - Vision Master Calibration - Result output (Message) -
Filtering - PLC Master Calibration -
Search II OK Result output (Parallel I /
O)
-
Additional Information
Some processing items are processed in parallel as individual units.
l
Troubleshooting
Symptom Correction
An error message is dis-
played on the Console Win-
dow.
Refer to the error message list.
Insertion position for a unit to
parallelize
Do not place items between the Parallelize item and Parallelize Task item.
Any process units that are placed in that position will not be executed.
Insertion position of a paral-
lelize processing items
Always insert the Parallelize Task processing item between Parallelize and
Parallelize End processing items.
Setting the Parallelize proc-
essing item
Always use Parallelize and Parallelize End processing items in pairs.
Camera Image Input proc-
essing items are not being
processed in parallel
Do not insert Camera Image Input processing items under Parallelize Tasks
processing items.
To use a different Camera image for a measurement under a Parallelize
Task processing item, use the Camera Switching processing item under the
Parallelize Task processing item.
Getting and setting the im-
age from more than one Par-
allelize Task processing item
Do not reference an image that is processed under a different Parallelize
Task processing item.
Getting and setting data from
more than one Parallelize
Task processing item
Do not get or set figure data from a processing unit that is inside the range
of a different Parallelize Task processing item.
Do not get or set unit data from a processing unit that is inside the range of a
different Parallelize Task processing item.
Accessing files from under
more than one Parallelize
Task processing item
Do not input or output to the same file from a processing unit that is under a
different Parallelize Task processing item.
Conditional branching under
a Parallelize Task processing
item
If you need to branch the processing items inside the range of a Parallelize
Task processing item, make sure the branch stays within the range of the
Parallelize Task processing item.
Processing order of Parallel-
ize Tasks
The processing order for the Parallelize Task processing units is not defined.
Do not program a measurement flow that relies on a specific processing or-
der of Parallelize Task processing items.
4 Setting the Controller
4 - 36
FH/FHV Series Vision System User’s Manual (Z365-E1)
