Editing Name and Type of a Variable
1 On the Edit item tab area in the Edit flow tab screen, click Scene variable tab or System
variable tab.
The Scene variable tab screen or the System variable tab screen is displayed.
The following is an example of the Scene variable tab screen.
2 On the Variable list area, select a variable name to edit.
Additional Information
The following operation also enables variable names to edit.
• Click the variable name to edit.
3 Click ... at the right of the Type column for the selected variable.
The Rename dialog box is displayed.
4 Edit the Variable name and the Type.
5 Click OK to end the input.
Editing Number of Elements of an Array Type Variable
When Array type variables are used, set the number of elements.
1 On the Edit item tab area in the Edit flow tab screen, click Scene variable tab or System
variable tab.
The Scene variable tab screen or the System variable tab screen is displayed.
The following is an example of the Scene variable tab screen.
5 Creating Measurement Scenes
5 - 48
FH/FHV Series Vision System User’s Manual (Z365-E1)
