Precautions for Correct Use
Note that some setting cannot be keep when you load the security setting saved as the older
version than the current software version.
For details, refer to Loading security settings from an older software version on page 10 - 38.
1 If the settings were stored in external storage, insert the external storage device containing the
security settings to load into the Sensor Controller.
2
In the Main Window, select Security settings from the Tool menu.
The Security settings dialog box is displayed.
3
Click the Setting data tab in the Item Tab Area.
4
Select the file to load from the Load from file area.
5
Click the Load button.
l
Loading security settings from an older software version
When loading security settings from a previous Sensor Controller software version, the settings
that can be transferred will differ depending on the that previous software version.
Refer to the following table. Confirm each setting item and reset as needed.
(1) Loading the security settings in software version 4.12, or earlier.
Setting item Keep Discard
Password YES
Switch to ADJUST mode YES
Non-stop adjustment mode YES
RUN Control area YES
RUN Tool box YES
Additional Information
For the password setting set in FZ4 Ver4.12, or earlier.
For details, refer to Transferring Old Security Settings on page 10 - 41.
(2) Loading the security settings in version from 4.20 to 4.24.
Setting item Keep Discard
Layout restrictions
Switch to ADJUST mode YES
Switch to RUN mode YES
ADJUST Control area YES
ADJUST Test measurement YES
ADJUST Detail result YES
ADJUST Image display YES
RUN Control area YES
RUN flow YES
RUN Detail result YES
10 Advanced Usage
10 - 38
FH/FHV Series Vision System User’s Manual (Z365-E1)
