Menu Tables
FQ2 User’s Manual
405
Appendices
12
Image adjustment
Add filter These commands are used to add, mod-
ify, delete, copy, or change the name of
filter items and position compensation
items.
Color Gray Filter, Weak Smoothing,
Strong Smoothing, Dilate, Erosion,
Median, Extract Edges, Extract
Horiz. Edges, Extract vertical edges,
Enhance edges, Background Sup-
pression
Scene p. 70
Add pos. comp. Model Shape Sear. pos. comp., Search
position comp.
Scene p. 74
Edge Edge position comp., 2Edge position
comp. 2ed. midp. comp.Edge rot.
pos. Comp.
Scene p. 74
Modify --- --- p. 70
Delete --- --- p. 70
Copy --- --- p. 70
Rename 15 alphanumeric characters --- p. 70
Image adjustment (filter)
(Color Gray Filter)
Filter type You can specify the ranges of colors to
which the Color Gray Filter item is
applied.
RGB (default), HSV Scene p. 71
Filter settings Select the type of color filter to use. Custom filter, HSV Scene p. 71
Source image You must set the image to which the filter
is to be applied.
Camera, Prev. (default) Scene p. 70
(Items other than Color Gray Filter)
Filter region You can specify the region to which to
apply the filter.
--- Scene p. 71
Source image You must set the image to which the filter
is to be applied.
Camera, Prev. (default) Scene p. 70
Suppression level
(for Background
Suppression Item
Only)
The range in which to enhance the con-
trast and the brightness range to extract
are set for the Background Suppression
item.
--- Scene p. 72
Menu command Description Setting range Data Refer-
ence
