Omron NX701-1 User Manual

Appendices
A-26
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
Parameter Meaning Set value
Modulo Maximum Posi-
tion Setting Value
Set the modulo maximum position that is set
on the Servo Drive or the Encoder Input Ter-
minal.
This setting must agree with the maxi-
mum value that is set for the ring
counter in the Encoder Input Terminal.
Modulo Minimum Posi-
tion Setting Value
Set the modulo minimum position that is set
on the Servo Drive or the Encoder Input Ter-
minal.
Set this parameter to 0.
