3 Configuring Axes and Axes Groups
3-18
NJ/NX-series CPU Unit Motion Control User’s Manual (W507)
Changing Axis Variable Names in the User Program
Perform the following two procedures to change Axis Variable names that are already used.
• Change the Axis Variable name in the variable table in the variable declarations.
• Change the Axis Variable name in the user program.
Even if you change the Axis Variable names in the variable table, the Axis Variable names in the
user program do not change. An error will occur if you use a variable name that is not declared in
the variable table, in the user program. Always change the names in both places.
Use the Synchronization menu command of the Sysmac Studio to download the project to the CPU
Unit.
1
Select Online from the Controller Menu. The Sysmac Studio goes online with the Controller.
2
Select Synchronization from the Controller Menu and then click the Transfer to Controller
Button.
Downloading to the CPU Unit
To Next Page
