7 PLC Setup
7-14
CP2E CPU Unit Software User’s Manual(W614)
2 2-1 2-1-6 Received Bytes (set-
ting)
256 bytes 256 bytes When power is turned ON
1 byte
:
255 bytes
2-1-7 Set End Code (setting) 00 Hex 00 Hex When power is turned ON
:
FF Hex
2-1-8 Delay 0 ms 0 (×10 ms) When power is turned ON
:
9999 (×10 ms)
22-3 Modbus-RTU Easy Master Settings
2-3-1 Baud 9,600 bps 1,200 bps When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-3-2 Format
(data length, stop bits,
parity)
7 bits, 2 bits, even 7 bits, 2 bits, even When power is turned ON
7 bits, 2 bits, odd
7 bits, 2 bits, no parity
7 bits, 1 bit, even
7 bits, 1 bit, odd
7 bits, 1 bit, no parity
8 bits, 2 bits, even
8 bits, 2 bits, odd
8 bits, 2 bits, no parity
8 bits, 1 bit, even
8 bits, 1 bit, odd
8 bits, 1 bit, no parity
2-3-3 Response Timeout 5 s 0 (5 s) When power is turned ON
1 (×100 ms)
:
255 (×100 ms)
2-4 PC Link (Slave) Settings
2-4-1 Baud 9,600 bps 1,200 bps When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-4-2 PLC Link Unit No. 0 0 When power is turned ON
:
7
Name Default Possible settings
When setting is read by
CPU Unit
