Omron SYSMAC CP Series User Manual

7-21
7 PLC Setup
CP2E CPU Unit Software User’s Manual(W614)
7-2 PLC Setup Settings
7
7-2-10 Pulse Output 2 Settings
The settings are applicable to the N30/40/60 CPU Units with transistor outputs.
Origin Return Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
2 Acceleration Ratio (rate) 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
3 Deceleration rate 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
7-2-10 Pulse Output 2 Settings
Base Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Undefined Origin (operation for limit signal
turning ON)
Hold Hold At start of operation
Undefined
2 Limit Input Signal Operation Search Only Search Only When power is turned ON
Always
3 Limit Input Signal NC NC At start of operation
NO
4 Search/Return Initial Speed 0 pps 0 pps At start of operation
:
100,000 pps
Origin Search Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Use define origin operation Do not use. Do not use. When power is turned ON
Use.
1-1 Search Direction CW CW At start of operation
CCW
1-2 Detection Method Method 0 Method 0 At start of operation
Method 1
Method 2
1-3 Search Operation Inverse 1 Inverse 1 At start of operation
Inverse 2
1-4 Operation Mode Mode 0 Mode 0 At start of operation
Mode 1
Mode 2
1-5 Origin Input Signal NC NC At start of operation
NO
1-6 Proximity Input Signal NC NC At start of operation
NO
