Omron SYSMAC CP Series - 8 Overview of Built-in Functions and Allocations

8-1
CP2E CPU Unit Software User’s Manual(W614)
8
This section describes the built-in functions, overall procedure, and allocations for func-
tions of the CP2E.
8-1 Built-in Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
8-2 Overall Procedure for Using CP2E Built-in Functions. . . . . . . . . . . . . . . . . 8-3
8-3 Terminal Allocations for Built-in Functions . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8-3-1 Specifying the Functions to Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8-3-2 Selecting Functions in the PLC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-4
8-3-3 Allocating Built-in Input Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-6
8-3-4 Allocating Built-in Output Temrinals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-8
Overview of Built-in Functions
and Allocations
