7 PLC Setup
7-18
CP2E CPU Unit Software User’s Manual(W614)
The settings are applicable to the N/S-type CPU Units with transistor outputs.
7IN8: CIO 0.08
(N20/30/40/60 CPU Unit only)
Normal Normal When power is turned ON
Interrupt
Quick
8 IN9: CIO 0.09
(N20/30/40/60 CPU Unit only)
Normal Normal When power is turned ON
Interrupt
Quick
7-2-8 Pulse Output 0 Settings
Base Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Undefined Origin (operation for limit signal
turning ON)
Hold Hold At start of operation
Undefined
2 Limit Input Signal Operation Search Only Search Only When power is turned ON
Always
3 Limit Input Signal NC NC At start of operation
NO
4 Search/Return Initial Speed 0 pps 0 pps At start of operation
:
100,000 pps
Origin Search Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Use define origin operation Do not use. Do not use. When power is turned ON
Use.
1-1 Search Direction CW CW At start of operation
CCW
1-2 Detection Method Method 0 Method 0 At start of operation
Method 1
Method 2
1-3 Search Operation Inverse 1 Inverse 1 At start of operation
Inverse 2
1-4 Operation Mode Mode 0 Mode 0 At start of operation
Mode 1
Mode 2
1-5 Origin Input Signal NC NC At start of operation
NO
1-6 Proximity Input Signal NC NC At start of operation
NO
1-7 Search High Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
1-8 Search Proximity Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
Name Default Possible settings
When setting is read by
CPU Unit
