Omron SYSMAC CP Series User Manual

7 PLC Setup
7-16
CP2E CPU Unit Software User’s Manual(W614)
7-2-7 Built-in Inputs
High-speed Counter Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Use high-speed counter 0 Do not use. Do not use. When power is turned ON
Use.
1-1 Counting mode Linear mode Linear mode At start of operation
Circular mode
1-1-1 Circular Max. Count 0 0 At start of operation
:
4,294,967,295
1-2 Reset
Note Only a software reset can be
set if an increment pulse
input is set for the input set-
ting.
Z phase, software reset
(stop comparing)
Z phase, software reset (stop
comparing)
When power is turned ON
Software reset (stop comparing)
Phase Z, software reset (compar-
ing)
Software reset (comparing)
1-3 Input Setting
Note Make the same input setting
for high-speed counters 0, 1,
and 2.
Differential phase input
(×4)
Differential phase input (×4) When power is turned ON
Pulse + direction input
Up/Down pulse input
Increment pulse input
2 Use high-speed counter 1 Do not use. Do not use. When power is turned ON
Use.
2-1 Counting mode Linear mode Linear mode At start of operation
Circular mode
2-1-1 Circular Max. Count 0 0 At start of operation
:
4,294,967,295
2-2 Reset
Note Only a software reset can be
set if an increment pulse
input is set for the input set-
ting.
Z phase, software reset
(stop comparing)
Z phase, software reset (stop
comparing)
When power is turned ON
Software reset (stop comparing)
Phase Z, software reset (compar-
ing)
Software reset (comparing)
2-3 Input Setting
Note Make the same input setting
for high-speed counters 0, 1,
and 2.
Differential phase input
(×4)
Differential phase input (×4) When power is turned ON
Pulse + direction input
Up/Down pulse input
Increment Pulse input
3 Use high-speed counter 2 Do not use. Do not use. When power is turned ON
Use.
3-1 Counting mode Linear mode Linear mode At start of operation
Circular mode
3-1-1 Circular Max. Count 0 0 At start of operation
:
4,294,967,295
3-2 Reset Software reset Software reset When power is turned ON
Software reset (comparing)
3-3 Input
Setting
Increment pulse input Increment pulse input When power is turned ON
