7 PLC Setup
7-22
CP2E CPU Unit Software User’s Manual(W614)
The settings are applicable to the N30/40/60 CPU Units with transistor outputs.
1
1-7 Search High Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
1-8 Search Proximity Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
1-9 Origin Compensation Value 0 pps -2,147,483,648 At start of operation
:
0
:
+2,147,483,647
1-10 Origin Search Acceleration Ratio
(Rate)
0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
1-11 Origin Search Deceleration Ratio
(Rate)
0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
1-12 Positioning Monitor Time 0 (ms) 0 (ms) At start of operation
:
9,999 (ms)
Origin Return Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
2 Acceleration Ratio (rate) 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
3 Deceleration rate 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
7-2-11 Pulse Output 3 Settings
Base Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Undefined Origin
(operation for limit signal turning ON)
Hold Hold At start of operation
Undefined
2 Limit Input Signal Operation Search Only Search Only When power is turned ON
Always
3 Limit Input Signal NC NC At start of operation
NO
4 Search/Return Initial Speed 0 pps 0 pps At start of operation
:
100,000 pps
Name Default Possible settings
When setting is read by
CPU Unit
