Omron SYSMAC CP Series User Manual

7-13
7 PLC Setup
CP2E CPU Unit Software User’s Manual(W614)
7-2 PLC Setup Settings
7
7-2-6 Serial Option Port 1 (EX)
The settings are applicable to the N-type CPU Units when Serial Option Board CP2W-CIFD with
2 ports is mounted.
Since this setting is reflected by power OFF and ON, the PLC Setup and the actual operation settings-
may be different. The actual operation settings can be confirmed in words A616.
7-2-6 Serial Option Port 1 (EX)
Communications Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Communications Settings Standard (9600;
1, 7, 2, E)
(Default settings)
Standard
Baud rate: 9,600 bps
Start bits: 1 bit
Data length: 7 bits
Parity: Even
Stop bits: 2 bits
When power is turned ON
Custom
2 Mode
(When custom settings have been
selected.)
RS-232C (No-protocol) RS-232C (No-protocol) When power is turned ON
PC Link (Slave)
PC Link (Master)
Modbus-RTU Easy Master
Modbus RTU Slave
2-1 RS-232C (No-protocol) Settings
2-1-1 Baud 9,600 bps 1,200 bps When power is turned ON
2,400 bps
4,800 bps
9,600 bps
19,200 bps
38,400 bps
57,600 bps
115,200 bps
2-1-2 Format
(data length, stop bits,
parity)
7 bits, 2 bits, even 7 bits, 2 bits, even When power is turned ON
7 bits, 2 bits, odd
7 bits, 2 bits, no parity
7 bits, 1 bit, even
7 bits, 1 bit, odd
7 bits, 1 bit, no parity
8 bits, 2 bits, even
8 bits, 2 bits, odd
8 bits, 2 bits, no parity
8 bits, 1 bit, even
8 bits, 1 bit, odd
8 bits, 1 bit, no parity
2-1-3 Start Code Disable. Disable. When power is turned ON
Set.
2-1-4 Start Code (setting) 00 Hex 00 Hex When power is turned ON
:
FF hex
2-1-5 End Code None
(Received Bytes)
Received Bytes (no end code) When power is turned ON
CR, LF
Set End Code
