7 PLC Setup
7-4
CP2E CPU Unit Software User’s Manual(W614)
Note The input constants of CP1W-40EDR/EDT/EDT1 are always 16ms regardless of the settings.
7-2-2 Timing and Interrupt Settings
Timing and Interrupt Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Watch Cycle Time No setting (1s) Setting At start of operation
1: 1 × 10 ms
:
100: 100 × 10 ms
2 Constant Cycle Time No setting (variable) Setting At start of operation
1ms
:
1,000 ms
7-2-3 Input Constants Settings
Input Constants
Name Default Possible settings
When setting is read by
CPU Unit
1 0CH: CIO 0 8 ms No filter (0 ms) When power is turned ON
1 ms
2 ms
4 ms
8 ms
16 ms
32 ms
2 1CH: CIO 1 Same as above. Same as above. Same as above.
3 2CH: CIO 2
4 3CH: CIO 3
5 4CH: CIO 4
6 5CH: CIO 5
7 6CH: CIO 6
8 7CH: CIO 7
9 8CH: CIO 8
10 9CH: CIO 9
11 10CH: CIO 10
12 11CH: CIO 11
13 12CH: CIO 12
14 13CH: CIO 13
15 14CH: CIO 14
16 15CH: CIO 15
17 16CH: CIO 16
18 17CH: CIO 17
