Omron SYSMAC CP Series User Manual

7 PLC Setup
7-24
CP2E CPU Unit Software User’s Manual(W614)
The settings are applicable to the N-type CPU Units.
Origin Return Settings
Name Default Possible settings
When setting is read by
CPU Unit
1 Speed 0 pps (disabled) 1 pps At start of operation
:
100,000 pps
2 Acceleration Ratio (rate) 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
3 Deceleration rate 0 (disabled) 1 (pulse/4 ms) At start of operation
:
65,535 (pulse/4 ms)
7-2-12 Built-in Ethernet Settings
Ethernet Port Settings
Name Default Possible Settings
When Setting is read by
CPU Unit
1 Broadcast Address 4.3BSD 4.3BSD When power is turned ON or
when Ethernet is reset
4.2BSD
2 IP Address 0.0.0.0 0.0.0.0 When power is turned ON or
when Ethernet is reset
:
255.255.255.255
3 Subnet Mask 0.0.0.0 0.0.0.0 When power is turned ON or
when Ethernet is reset
:
255.255.255.255
4 TCP Keep-alive Time 120 min
(Default value: 0)
0 (120 min) When power is turned ON or
when Ethernet is reset
1 min
:
65,535 min
5 FINS Node Address Node address 1
(Default value: 0)
0 (1) When power is turned ON or
when Ethernet is reset
:
254
FINS/TCP Settings
Name Default Possible Settings
When Setting is read by
CPU Unit
6 FINS/TCP Port Number Mode 9600 Default (9600) When power is turned ON or
when Ethernet is reset
User
FINS/TCP Port Number (User) 9600
(Default value: 0)
0 (9600) When power is turned ON or
when Ethernet is reset
1
:
65,535
7 IP Address Protect
(Only for FINS/TCP Server)
Not Protect Not Protect When power is turned ON or
when Ethernet is reset
Protect
