Oracle Database Appliance X6-2-HA Service Manual

Servicing Oracle Database Appliance X3-2/X4-2/X5-2 CRUs
Note - For the Oracle Database Appliance X6-2-HA, all of the CRUs on the storage
shelf and the storage expansion shelf can be replaced while the power is on. See “Oracle
Database Appliance X3-2/X4-2/X5-2 and X6-2-HA/X7-2-HA Storage Shelf Hot-Pluggable
Components” on page 78 for storage shelf component replacement procedures.
Note - The links in the following table take you to instructions outside of the Oracle Database
Appliance library to the Oracle Server X6-2 and Oracle Server X6-2L (including Storage Server
X6-2 Extreme Flash version) documentation libraries. Use your browser's Back button to return
to the Oracle Database Appliance library.
Oracle Database Appliance X6-2S/
X6-2M
Oracle Database Appliance X6-2L Oracle Database Appliance X6-2-HA
CRU List CRU List CRU List
Servicing DIMMs (CRU) Servicing DIMMs (CRU) Servicing DIMMs (CRU)
Servicing PCIe Risers (CRU) This system does not have PCIe
risers.
Servicing PCIe Risers (CRU)
Servicing PCIe Cards (CRU) Servicing PCIe Cards (CRU) Servicing PCIe Cards (CRU)
Servicing Internal USB Flash Drives
(CRU)
Servicing Internal USB Flash Drives
(CRU)
Servicing Internal USB Flash Drives
(CRU)
Servicing the Battery (CRU) Servicing the Battery (CRU) Servicing the Battery (CRU)
Servicing Oracle Database Appliance X3-2/X4-2/X5-2 CRUs
This section describes how to service customer-replaceable units (CRUs) for Oracle Database
Appliance X3-2/X4-2/X5-2.
If you have Oracle Database Appliance X7-2 series, go to “Servicing Oracle Database
Appliance X7-2 Series CRUs” on page 101. If you have Oracle Database Appliance X6-2
series, go to “Servicing Oracle Database Appliance X6-2 Series CRUs” on page 102. If
you have Oracle Database Appliance Version 1, go to “Servicing Oracle Database Appliance
Version 1 CRUs” on page 104.
Note - When adding DIMMs to the system, refer to the "Optional Component Installation"
section in the Owner's Guide for supported configurations.
This section describes how to service customer-replaceable units (CRUs) that require you to
power off the server.
Chapter 4 • Servicing CRUs That Require Server Node Power Off 103
