Oracle Database Appliance X7-2-HA Status Indicators
Callout Indicator/LED: Color State Meaning
server. When using an SFP28
port, network connectivity is
disabled on the 10GbE RJ-45
ports (NET 1 and NET 2).
■ Off – No activity.
■ Flashing – Packet activity.
Top right speed indicator:
■ Off – 10/100BASE-T link (if link up).
■ Amber On – 1000BASE-T link.
■ Green On – 10000BASE-T link.
10 NET 1 and 2 10/25 GbE SFP28
ports: green/amber
Note - The 10/25 GbE SFP28
(NET 1 and NET 2) ports are
the default network ports for the
server. When using an SFP28
port, network connectivity is
disabled on the 10GbE RJ-45
ports (NET 1 and NET 2).
10/25 GbE SFP28 interface.
Top activity indicator:
■ Off – No activity.
■ Flashing – Packet activity.
Bottom speed indicator:
■ Off – No activity.
■ Amber On – 10GbE link.
■ Green On – 25GbE link.
Oracle Database Appliance X7-2-HA Storage Shelf
Indicators
Storage shelves are supported with Oracle Database Appliance X7-2-HA. They include controls
and indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O
modules.
Storage Shelf Front Panel Status Indicators
The following figure shows the controls and indicators on the for the Oracle Database
Appliance X7-2-HA storage shelf (DE3-24C) front panel and drives.
Note - The 2 or 3 character LED enclosure ID display panel on the front of the storage shelf is
not used with the Oracle Database Appliance product. Any numbers or letters displayed in this
panel other than zeros could indicate a fault with either the panel, its cabling (neither of which
are customer replaceable), or some other storage shelf component.
20 Oracle Database Appliance Service Manual • November 2017
