Reset BIOS Password and Clear CMOS NVRAM Using CLR CMOS Button
See “Installing a Server Node Into the System Chassis” on page 246.
c.
Power on the server node.
See “Powering On Oracle Database Appliance Version 1” on page 249.
When the server node powers on and boots, it displays a message that indicates that
NVRAM has been cleared.
The CMOS NVRAM, including the BIOS password is cleared to its default state.
The default state for the BIOS passwords is that no password is required. To set a BIOS
password, see “BIOS Security Menu Screen” on page 279.
4.
Verify that the Power/OK LED is lit on the server node.
Ethernet Port Naming and Boot Order
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
Each Oracle Database Appliance Version 1 server node supports two 10/100/1000Base-T
Gigabit Ethernet ports on the rear of the chassis. For port locations, see the Oracle Database
Appliance Owner's Guide.
The device naming for the Ethernet interfaces is reported differently by different interfaces
and operating systems. See the following table for the physical (BIOS) and logical (operating
system) naming conventions used for each interface.
Interface NET0 NET1
BIOS NET0 NET1
Oracle Linux eth0 eth1
The order in which the BIOS detects the Ethernet ports during boot time, and the corresponding
drivers that control those ports, are listed below:
1. NET 0 (INTEL NIC 0)
2. NET 1 (INTEL NIC 1)
Appendix A • Servicing the Oracle Database Appliance Version 1 259
