Oracle Database Appliance X6-2-HA Service Manual

Install PCIe Riser in Server Nodes
Servicing PCIe Cards (CRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes servicing PCIe cards in Oracle Database Appliance Version 1.
■
“PCIe Card Configuration” on page 182
■
“Remove PCIe Card From PCIe Riser” on page 183
■
“Install PCIe Card in PCIe Riser” on page 184
■
“Remove Primary HBA PCIe Card From Motherboard” on page 187
■
“Install Primary HBA PCIe Card in Motherboard” on page 188
PCIe Card Configuration
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 PCIe expansion system includes one standalone
low-profile slot on the motherboard and a PCIe riser with three slots. These are provisioned as
follows:
■
Motherboard slot – A low-profile, dual-port SAS-2 HBA used internally
■
PCIe slot 2 – Dual-port SAS-2 HBA used internally
■
PCIe slot 1 – Quad-port 1-Gb Ethernet NIC
■
PCIe slot 0 – Dual-port 10-Gb Ethernet NIC
Caution - If you replace a PCIe card, ensure the replacement is identical to the card you are
replacing.
182 Oracle Database Appliance Service Manual • November 2017
