Remove PCIe Card From PCIe Riser
Remove PCIe Card From PCIe Riser
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing a PCIe card from its riser in Oracle Database Appliance
Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
See “Performing Electrostatic Discharge and Antistatic Prevention
Measures” on page 146.
b.
Remove the server node from the system.
Power is removed from the server node when you remove it from the system. See
“Removing Server Nodes From the System Chassis” on page 147.
c.
Remove the server node top cover.
See “Removing the Server Node Top Cover” on page 149.
2.
Locate the PCIe card in the PCIe riser that you want to remove.
See the "Oracle Database Appliance Version 1 Back Panel" section of the Oracle Database
Owner's Guide for the location of the PCIe slots.
3.
If necessary, make a note of where the PCIe cards are installed.
4.
Disconnect all data cables from the PCIe card.
To disconnect a cable from the PCIe card, press the latch, push in toward the connector, and
then pull out to remove the cable.
Note the location of all cables for reinstallation later.
5.
Remove the PCIe riser.
See “Remove PCIe Riser From Server Nodes” on page 178.
6.
Remove the PCIe card from the riser.
Appendix A • Servicing the Oracle Database Appliance Version 1 183
