Oracle Database Appliance X6-2-HA Service Manual

Remove Air Duct
■
“Servicing the Power Distribution Board (FRU)” on page 207
■
“Servicing the Disk Midplane Module (FRU)” on page 212
■
“Servicing the Disk Midplane Module HDD Cable (FRU)” on page 219
■
“Servicing the Front Indicator Panels (FRU)” on page 222
■
“Servicing Server Node Cables” on page 227
■
“Servicing the Motherboard Assembly (FRU)” on page 240
Removing and Installing the Air Duct (FRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The air duct for the Oracle Database Appliance Version 1 must be removed to service the CPUs.
The air duct is a FRU and can only be replaced by an Oracle-qualified service technician.
Caution - Equipment overheating. Ensure that the air duct is installed correctly before
powering on the server.
This section includes the following topics:
■
“Remove Air Duct” on page 194
■
“Install Air Duct” on page 196
Remove Air Duct
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the air duct from Oracle Database Appliance Version 1.
1.
Prepare the server node for service.
a.
Attach an antistatic wrist strap.
194 Oracle Database Appliance Service Manual • November 2017
