Install Power Distribution Board
d.
To secure the power distribution board to the system, use the holes in the
system side wall to access and tighten the two Phillips screws [3].
e.
Reconnect the power distribution board ribbon cable [4].
2.
Return the system to operation.
a.
Install both server nodes into the system.
See “Installing a Server Node Into the System Chassis” on page 246.
b.
Install the middle section of the top cover.
Install and tighten the Phillips screws that secure the middle section of the top cover to the
system chassis.
c.
Install both power supplies into the system.
See “Install a Power Supply” on page 165.
d.
If the system was installed in a rack, reinstall it into the rack.
See the Oracle Database Appliance Owner's Guide for instructions.
e.
Reconnect the power cords to the system and power on the system.
See “Powering On Oracle Database Appliance Version 1” on page 249.
Servicing the Disk Midplane Module (FRU)
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
The Oracle Database Appliance Version 1 disk midplane interconnects the front disk drives to
the server nodes, the front indicator modules, and the power distribution board (PDB).
The disk midplane board is a FRU and can only be replaced by an Oracle-qualified service
technician.
212 Oracle Database Appliance Service Manual • November 2017
