Remove Disk Midplane Module
Caution - Equipment damage. Follow antistatic precautions as described in “Performing
Electrostatic Discharge and Antistatic Prevention Measures” on page 146. Do not touch the
components along their connector edges.
Caution - Equipment damage. Remove all power from the system before removing or
installing the disk midplane board. Power down both server nodes (also called system
controllers) and disconnect the power cords from the system before performing these
procedures. For instructions, see “Shutting Down a Server Node and Powering Off the
System” on page 143.
This section includes:
■
“Remove Disk Midplane Module” on page 213
■
“Install Disk Midplane Module” on page 217
Remove Disk Midplane Module
Note - Information in this appendix does NOT apply to Oracle Database Appliance X3-
2, Oracle Database Appliance X4-2, Oracle Database Appliance X5-2 or Oracle Database
Appliance X6 series. Refer to the preceding chapters in this document for information on
servicing those systems.
This section describes removing the disk midplane module from Oracle Database Appliance
Version 1.
1.
Prepare the system for service.
a.
Power off the system.
See “Shutting Down a Server Node and Powering Off the System” on page 143.
b.
Disconnect the power cords from the system.
c.
If the system is installed in a rack, remove it.
See the Oracle Database Appliance Owner's Guide for information on racking the system
chassis.
d.
Remove both power supplies from the system.
See “Remove a Power Supply” on page 164.
Appendix A • Servicing the Oracle Database Appliance Version 1 213
To Next Page
