Oracle Database Appliance X6-2-HA Service Manual

Oracle Database Appliance X3-2/X4-2 Status Indicators
Callout Indicator/LED: Color State Meaning
■ Off – No link activity.
Oracle Database Appliance X3-2/X4-2 Status Indicators
This section describes the status indicators for Oracle Database Appliance X3-2 and Oracle
Database Appliance X4-2.
■
“Oracle Database Appliance X3-2/X4-2 Server Node Status Indicators” on page 45
■
“Oracle Database Appliance X3-2/X4-2 Storage Shelf Status Indicators” on page 49
Oracle Database Appliance X3-2/X4-2 Server Node
Status Indicators
This topic describes Oracle Database Appliance X3-2 and Oracle Database Appliance X4-2
server node status indicators (LEDs).
Server Node Front Panel Status Indicators
The Oracle Database Appliance X3-2/X4-2 server node front panel includes indicators for the
system and storage drives.
Chapter 1 • Overview of System Status Indicators and LEDs 45
