Oracle Database Appliance X5-2 Status Indicators
Callout Indicator/LED: Color State Meaning
■ Yellow blinking – Data being passed.
8 NET 0-3 ports: green/amber 100/1000 BASE-T Ethernet management interface.
Top left activity indicator:
■ On – No function.
■ Off – No activity.
■ Blinking – Packet activity.
Top right link indicator:
■ On – Amber for 100 base-T link; green for 1000 base-T link.
■ Off – No link.
■ Blinking – No function.
Oracle Database Appliance X5-2 Storage Shelf
Status Indicators
Storage shelves are supported with Oracle Database Appliance X5-2. They include controls and
indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O modules.
Storage Shelf Front Panel Status Indicators
The following figure shows the controls and indicators on the Oracle Database Appliance X5-2
storage shelf (DE2-24C) front panel and drives.
Note - The 2 or 3 character LED enclosure ID display panel on the front of the storage shelf is
not used with the Oracle Database Appliance product. Any numbers or letters displayed in this
panel other than zeros could indicate a fault with either the panel, its cabling (neither of which
are customer replaceable), or some other storage shelf component.
42 Oracle Database Appliance Service Manual • November 2017
