Oracle Database Appliance X6-2-HA Service Manual

Preparing Oracle Database Appliance Version 1 for Service
Note - The links in the following table take you to instructions outside of the Oracle Database
Appliance library to the Sun Server X3-2, Sun Server X4-2, and Oracle Server X5-2
documentation libraries. Use your browser's Back button to return to the Oracle Database
Appliance library.
Oracle Database Appliance X3-2 Oracle Database Appliance X4-2 Oracle Database Appliance X5-2
Safety Precautions Safety Precautions Safety Precautions
Safety Symbols Safety Symbols Safety Symbols
Electrostatic Discharge Safety Electrostatic Discharge Safety Electrostatic Discharge Safety
Required Tools Required Tools Required Tools
Powering Down the Server Powering Down the Server Powering Down the Server
Disconnect Cables From the Server Disconnect Cables From the Server Disconnect Cables From the Server
Extend the Server to the
Maintenance Position
Extend the Server to the
Maintenance Position
Extend the Server to the
Maintenance Position
Remove the Server From the Rack Remove the Server From the Rack Remove the Server From the Rack
Take Antistatic Measures Take Antistatic Measures Take Antistatic Measures
Remove the Server Top Cover Remove the Server Top Cover Remove the Server Top Cover
Preparing Oracle Database Appliance Version 1 for Service
This section describes how to prepare Oracle Database Appliance Version 1 for servicing.
If you have Oracle Database X7-2 series, go to “Preparing Oracle Database Appliance X7-2
Series for Service” on page 61. If you have Oracle Database X6-2 series, go to “Preparing
Oracle Database Appliance X6-2 Series for Service” on page 62. If you have Oracle
Database Appliance X3-2, Oracle Database Appliance X4-2, or Oracle Database Appliance X5-
2, go to “Preparing Oracle Database Appliance X3-2/X4-2/X5-2 for Service” on page 63.
■
“Component Replacement Policy (CRUs and FRUs)” on page 140
■
“Safety Information” on page 141
■
“Required Tools ” on page 142
■
“Obtaining the Chassis Serial Number” on page 142
■
“Shutting Down a Server Node and Powering Off the System” on page 143
■
“Performing Electrostatic Discharge and Antistatic Prevention Measures” on page 146
■
“Removing Server Nodes From the System Chassis” on page 147
■
“Removing the Server Node Top Cover” on page 149
■
“Removing the Middle Section of the System Top Cover” on page 150
64 Oracle Database Appliance Service Manual • November 2017
