Page #31 background image
Oracle Database Appliance X6-2-HA Status Indicators
Callout Indicator/LED: Color State Meaning
Slow blink – Normal operation. Input power is within
specification. DC output voltage is not enabled.
7 System locate, service required
and OK: various
These operate in the same way as on the front panel.
8 NET 0-3 ports: green/amber 100/1000/10000 BASE-T Ethernet management interface.
Top left activity indicator:
On – No function.
Off – No activity.
Blinking – Packet activity.
Top right link indicator:
Off – 10/100BASE-T link (if link up).
Amber On – 1000BASE-T link.
Green On – 10000BASE-T link.
Oracle Database Appliance X6-2-HA Status Indicators
The following topics describe the Oracle Database Appliance X6-2-HA status indicators. They
include controls and indicators on the server nodes and storage shelf front panel, hard drives,
SSD drives, power supplies, and SAS I/O modules.
“Oracle Database Appliance X6-2-HA Server Node Status Indicators” on page 31
“Oracle Database Appliance X6-2-HA Storage Shelf Indicators” on page 35
Oracle Database Appliance X6-2-HA Server Node
Status Indicators
These topics describe Oracle Database Appliance X6-2-HA server node status indicators
(LEDs).
Server Node Front Panel Status Indicators
The Oracle Database Appliance X6-2-HA server node front panel includes indicators for the
system and storage drives.
Chapter 1 • Overview of System Status Indicators and LEDs 31
