Oracle Database Appliance X6-2-HA Service Manual

Managing System Faults on Oracle Database Appliance X3-2/X4-2/X5-2, X6-2 Series and X7-2 Series
series, go to “Servicing Oracle Database Appliance X6-2 Series FRUs” on page 108. If
you have Oracle Database Appliance Version 1, go to “Servicing Oracle Database Appliance
Version 1 FRUs” on page 120.
Only Oracle authorized service personnel should service FRU components.
Note - Most of the links in the following table take you to instructions outside of the Oracle
Database Appliance library to the Sun Server X3-2, Sun Server X4-2, and Oracle Server X5-2
documentation libraries. Use your browser's Back button to return to the Oracle Database
Appliance library.
Oracle Database Appliance X3-2 Oracle Database Appliance X4-2 Oracle Database Appliance X5-2
FRU Locations FRU Locations FRU List
Servicing Processors (FRU) Servicing Processors (FRU) Servicing Processors (FRU)
Servicing the Disk Backplane (FRU) Servicing the Disk Backplane (FRU) Servicing the Disk Backplane (FRU)
An optional DVD drive for this
system is considered a CRU.
See “Servicing Oracle Database
Appliance X3-2/X4-2/X5-2
CRUs” on page 103.
An optional DVD drive for this
system is considered a CRU.
See “Servicing Oracle Database
Appliance X3-2/X4-2/X5-2
CRUs” on page 103.
Servicing a DVD Drive (FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Front Indicator Module
(FRU)
Servicing the Motherboard (FRU) Servicing the Motherboard (FRU) Servicing the Motherboard (FRU)
Servicing the SAS Cables (FRU) Servicing the SAS Cables (FRU) Servicing the SAS Cables (FRU)
“Component Fault
Management” on page 120
“Component Fault
Management” on page 120
“Component Fault
Management” on page 120
Managing System Faults on Oracle Database Appliance X3-
2/X4-2/X5-2, X6-2 Series and X7-2 Series
This section describes how to manage system faults when servicing Oracle Database Appliance
X3-2/X4-2/X5-2, X6-2 series and X7-2 serries. If you have Oracle Database Appliance Version
1, go to “Servicing Oracle Database Appliance Version 1 FRUs” on page 120.
■
“Component Fault Management” on page 120
Chapter 5 • Servicing FRUs 119
