Oracle Database Appliance X6-2-HA Service Manual

Oracle Database Appliance X6-2-HA Status Indicators
Callout Indicator/LED: Color State Meaning
■ On – Green for link up.
■ Off – No link.
■ Blinking – Green for packet activity.
8 NET 0-3 ports: green/amber 100/1000/10000 BASE-T Ethernet management interface.
Top left activity indicator:
■ On – No function.
■ Off – No activity.
■ Blinking – Packet activity.
Top right link indicator:
■ Off – 10/100BASE-T link (if link up).
■ Amber On – 1000BASE-T link.
■ Green On – 10000BASE-T link.
Oracle Database Appliance X6-2-HA Storage Shelf
Indicators
Storage shelves are supported with Oracle Database Appliance X6-2-HA. They include controls
and indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O
modules.
Storage Shelf Front Panel Status Indicators
The following figure shows the controls and indicators on the for the Oracle Database
Appliance X6-2-HA storage shelf (DE3-24C) front panel and drives.
Note - The 2 or 3 character LED enclosure ID display panel on the front of the storage shelf is
not used with the Oracle Database Appliance product. Any numbers or letters displayed in this
panel other than zeros could indicate a fault with either the panel, its cabling (neither of which
are customer replaceable), or some other storage shelf component.
Chapter 1 • Overview of System Status Indicators and LEDs 35
