Table 1. Location and Description of Major Components. - Continued
24
QUICK-DISCONNECT COUPLING. Used to connect air hose from BII (WP 0114,
Table 3, Item 22) to vehicle air system. Air hose is used to manually inflate tires or
power air wrench. (WP 0114, Table 3, Item 44)
25
NO. 2 FUEL TANK. A 100 gal. (379 L) tank stores diesel engine operating fuel.
26
SPARE TIRE. Used to replace a damaged tire. (WP 0108)
27
NO. 2 AXLE. Supports weight of HET Tractor and transmits power to hubs to turn
rear wheels.
28
NO. 3 AXLE. Supports weight of HET Tractor and transmits power to hubs to turn
rear wheels.
29
NO. 4 AXLE. Supports weight of HET Tractor and assists No. 1 axle in steering
(WP 0006) when in motion. Transmits power to hubs to turn rear wheels.
30
TOW EYES. Attachment points for towing operations.
31
ELECTRICAL CONNECTOR. A 12-volt (7-pin) connector supplies power to trailer
or to towed vehicle electrical system through the intervehicular cable. (WP 0114,
Table 3, Item 8).
32
PINTLE HOOK. Hitch used for towing trailer or another vehicle using the tow bar.
(WP 0070)
33
GLADHANDS. Couples air supply to another vehicle or trailer during towing or
trailering operations.
34
APPROACH RAMPS. Raise the front end of trailer to guide kingpin into fifth wheel.
35
FIFTH WHEEL. Couples trailer to HET Tractor. (WP 0034)
END OF WORK PACKAGE
