OPERATOR MAINTENANCE
EQUIPMENT DATA
Table 1. Vehicle Dimensions.
Width (vehicle): 102 in. (2 591 mm)
Width (mirrors extended): 144 in. (3 658 mm)
Height (overall): 140.1 in. (3 559 mm)
Length (overall): 361.6 in. (9 185 mm)
Wheelbase: 215 in. (5 461 mm)
Track: 82 in. (2 083 mm)
5th Wheel Height: 64 in. (1 626 mm)
Kingpin Diameter: 3.5 in. (89 mm)
Ground Clearance: 15.9 in. (404 mm)
Table 2. Weights and Payloads.
HET Tractor Curb Weight: 38,910 lbs (17 665 kg)
Gross Vehicle Weight Rating (GVWR): 86,000 lbs (39 044 kg)
Gross Combination Weight Rating (GCWR): 231,400 lbs (105 056 kg)
Kingpin Load: 46,000 lbs (20 884 kg)
Table 3. Weight Distribution.
Axle Loads of HET Tractor (Curb Weight)
No. 1 Axle: 17,620 lbs (7 999 kg)
TM 9-2320-360-10 0005
0005-1
