Table 1. PMCS - BEFORE - Continued
Item
No.
Interval
Item to
be
Checked
or
Serviced
Procedure
Equipment
Not Ready/
Available If:
7. Check AIR CLEANER
RESTRICTION indicator (5).
Press RESET button if indicator
reads greater than 15 (in yellow
or red area). Notify your
Supervisor if indicator still reads
greater than 15 (in yellow or red
area).
Gauge
reads in red
area (ap-
proximately
230°F
[110°C] and
CHECK
GAUGES
indicator
lights/alarm
sounds.
8
7
6
5
9
BLACK
OUT
DRIVE
BLACK
OUT
MARKER
BLACK
OUT
LIGHTS
CHECK
GAUGES
CHECK
ENGINE
AIR
LOW
CROSS COUNTRY
HIGHWAY
MUD SAND & SNOW
9 MAX SPEED 45 MPH)
(MAX SPEED 30 MPH)
( MAX SPEED 15 MPH)
( MAX SPEED 5 MPH)
EMERGENCY
OVERSPEED
LOW AIR
START
CTI OFF - ON
CTI CONTROLLER MODEL 101
TRAILER
AIR SUPPLY
ENGINE
OFF
ON
START
FILTER MINDER
AIR CLEANER RESTRICTION
RESET
H O
2
—20—
—15—
—10—
— 8 —
PARKING
BRAKE
Figure 11.
8. Check AIR PRESS gauge (6) for
system air pressure level above
60 psi (414 kPa). Repeatedly
step on brake pedal until air
pressure drops below 60 psi (414
Gauge indi-
cation for ei-
ther section
is less than
60 psi (414
TM 9-2320-360-10 0100
0100-22
