Table 1. Location and Description of Major Components. - Continued
13
AIR RESERVOIRS. Store compressed air for operation of brake, suspension, and
central tire inflation systems.
14
NO. 1 FUEL TANK. A 150 gal. (568 L) tank which stores fuel used to operate
engine. Receives excess fuel not used by engine fuel injection system. Connects
to fuel tank No. 2 with hose and shutoff valve.
15
STOWAGE BOX. Used to stow Components Of End Item (COEI), Basic Issue
Items (BII), (WP 0114) and Additional Authorization List (AAL) (WP 0115) items.
16
FUEL/WATER SEPARATOR. Removes water and contaminants from fuel before
entering fuel pump. The unit incorporates a thermostatically activated electric
heater to prevent gelling of fuel in cold weather operation.
17
SLAVE RECEPTACLE. A 24-volt receptacle used to slave start (WP 0078) the
HET Tractor.
18
TOOL BOX. Used to stow Components Of End Item (COEI), Basic Issue Items
(BII), (WP 0114) and Additional Authorization List (AAL) (WP 0115) items.
TM 9-2320-360-10 0004
0004-4
