Chapter 1. Programming Site Data
8 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
Programming of the ACTIV, SYSTM (CH1/2 and GLOBL) and PIPE submenus is necessary for operation of the Model
DF868. Failure to accurately enter all of the required information will result in unreliable flow rate data. Therefore, be
sure to complete at least the sections of this chapter pertaining to those three submenus.
Note: Because it is so essential, instructions for programming the ACTIV, SYSTM and PIPE submenus are also
included in the Startup Guide. If that programming has already been completed, skip the corresponding
sections of this chapter.
Except for the three submenus noted above, it is not necessary to program the Model DF868 flowmeter in any
particular order. Therefore, the sections of this chapter need not be completed in sequence. Proceed immediately to
any section of interest.
1.5.1 Entering Programming Mode
To access the User Program, press the [PROG] key on the keypad. The standard measurement mode screen will be
replaced by the following initial programming mode screen:
Note:
If the security feature is active, enter the password and press the [ENT] key to enter the User Program. See the
SECUR submenu section of this chapter on page 50 for more information on the security feature.
PROGRAM Start ‰
Press the [ and [ keys and one of the function keys [F1]-[F4] to select the
desired submenu. From this screen, press [EXIT] to return to measurement
mode.
PROGRAM
Channel 1
CH1 CH2 GLOBL SAVE
To Next Page
