Chapter 4. Printing Data
80 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
4.4 Printing Logs
Use the LOG submenu to print logged measurement data, from a log file in the meter’s memory. The data may be
printed in either numeric or graphical format, with a user specified time increment.
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
To print logged measurement data, refer to Figure 16 on page 103, and complete the following steps:
1. To access the Print Menu, press the [PRNT] key.
Note: The Print Menu is not
protected by the security feature and a password is never required to access this
menu.
2. Press [F2] = LOG.
Note: The Print Menu is not
protected by the security feature and a password is never required to access this
menu.
3. Press [F1] to print the log in numeric format or press [F2] to print the log in graphical format.
4. Use the [
, [ and [F1]-[F4] keys to select a log file to print.
Note: At the NAME prompt, the option bar shows the names of all completed or active log files currently stored in
memory. If an active log is selected for printing, only the data already accumulated at the time of the print
command will be printed.
5. Enter the number of the first page of the log to print and press [ENT]. (This prompt does not appear if the log file
is only one page long.)
6. Enter the total number of log pages to print and press [ENT]. (This prompt does not appear if the log file is only
one page long.)
• If you pressed [F1] at step 3, go to Numeric Format on the next page.
• If you pressed [F2] at step 3, go to Graphical Format on the next page.
To Next Page
