DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel) 77
Chapter 4. Printing Data
4.3 Print Live Data
Use the DATA submenu to print live measurement data as it is collected. The data may be printed in either numeric
or graphical format, with a user specified time increment.
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
To print live measurement data, refer to Figure 16 on page 103, and complete the following steps:
1. To access the Print Menu, press the [PRNT] key.
Note: The Print Menu is not
protected by the security feature and a password is never required to access this
menu.
2. Press [F1] = DATA.
3. Press [F1] to print the data in numeric format or press [F2] to print the data in graphical format.
• If you press [F1], go to step 4.
• If you press [F2], go to step 8.
4.3.1 Numeric Format
4. Use the [, [ and [F1]-[F4] keys to select the first parameter to be printed. See Table 38 for a list of the
available options.
Refer to Chapter 3, Diagnostics, of the Service Manual for a discussion of the many parameters accessible via the
DIAG option.
Note: The units assigned to the parameters in Table 38 are those selected in the User Program (SYSTM submenu).
Table 38: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[
 + [F1] = MDOT*
Mass Flow
[
 + [F2] = +MASS*
Forward Totalized Mass Flow
[
 + [F3] = -MASS*
Reverse Totalized Mass Flow
[
 + [F4] = POWER**
Energy Flow Power
[
 + [ + [F1] = +ENRG**
Forward Energy Flow
[
 + [ + [F2] = -ENRG**
Reverse Energy Flow
[
 + [ + [F3] = DIAG
Diagnostic
* Available only if “Mass Flow (static)?” = YES
**Available only if “Energy Option” = YES
