Chapter 4. Printing Data
78 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
4.3.1 Numeric Format (cont.)
5. Use the [, [ and [F1]-[F4] keys to select the second parameter to be printed. See Table 38 on page 77 for a
list of the available options.
6. Use the [
, [ and [F1]-[F4] keys to select the third parameter to be printed. See Table 38 on page 77 for a list
of the available options.
7. Use the [
, [ and [F1]-[F4] keys to select the desired Time Increment (the frequency at which measurements
are taken). The available options at this prompt are: 5sec, 10sec, 30sec, 1min, 3min, 6min and 12min.
After the time increment is chosen, the Model DF868 returns to the standard data display screen and continues to
take measurements. The live data is printed at the specified time intervals, until a STOP command is issued (see the
instructions for the STOP submenu on page 83). A portion of a typical printout is shown in Figure 3.
Figure 3: A Typical Numeric Printout
DATA_DUMP OF (SITE NAME)
Site LABEL Site MESSAGE
Start Date
Start Time
HH:MM:SS
03:08:40 P
03:08:50 P
03:09:00 P
03:09:10 P
03:09:20 P
03:09:30 P
03:09:40 P
03:09:50 P
03:10:00 P
03:10:10 P
.
.
.
ACF/HR
686.85
684.00
678.12
680.58
.
.
670.70
675.99
669.79
675.59
662.28
666.71
.
VOLUM
232.57
236.34
234.46
.
.
.
ACF
230.45
228.58
226.71
224.84
222.70
220.83
218.92
+TOTL
20 OCT 97
03:08:40 PM
1039.082
.
.
1038.860
1039.255
.
FT/S
1039.511
1039.105
1039.137
1039.470
1039.509
1039.003
1039.147
SNDSP
