Chapter 1. Programming Site Data
10 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
1.6.2 Entering System Data for a Channel
IMPORTANT: Do not confuse this SYSTM submenu of the CH1/CH2 menu, which is used to enter channel-specific
information, with the SYSTM submenu of the GLOBL menu, which is used to enter information applicable
to both channels.
1. To enter the Channel PROGRAM menu, press [F1] or [F2] (depending on the desired channel) at the User
PROGRAM prompt.
2. To program the SYSTM submenu, press [F2] at the Channel PROGRAM prompt.
3. Enter a Channel Label of up to 9 characters. Press [ENT].
4. Enter a Channel Message of up to 21 characters. Press [ENT].
5. Press [F1] to turn the Energy Option OFF or press [F2] to turn it ON. (The Energy Option calculates the energy of a
system based on temperatures at the supply and return points, and the flow of fluid.)
6. Use the [F1]-[F4] and [
 and [ keys to select the desired Volumetric Units for the flow rate display.
Note: The above option bar shows English units, as an example.
The abbreviations and definitions of all the available volumetric units are shown in Table 2. The choices shown on the
option bar are determined by the selections made at the SYSTEM UNITS prompt in the GLOBL menu.
7. Press [F1]-[F4] to select the desired number of Decimal Digits (digits to the right of the decimal point) in the
volumetric flow rate display.
8. Use the [F1]-[F4] and [
 and [ keys to select the desired Totalizer Units for the totalized flow rate display.
The option bar above shows English units. If Metric units are specified in the GLOBL menu, these will appear instead.
Table 2: Volumetrics Units Options
English Volumetric Units Metric Volumetric Units
GAL/S U.S. Gallons per Second L/S L/S- Liter per Second
GAL/M U.S. Gallons per Minute L/M L/M - Liters per Minute
GAL/H GAL/H - U.S. Gallons per Hour L/H L/H - Liters per Hour
MGD Millions of U.S. Gallons per Day ML/D Millions of Liters per Day
ft
3
/s
Cubic Feet per Second
m
3
/s
Cubic Meters per Second
ft
3
/m
Cubic Feet per Minute
m
3
/m
Cubic Meters per Minute
ft
3
/h
Cubic Feet per Hour
Mm
3
/h
Millions of Cubic Meters per Hour
Mft
3
/d
Millions of Cubic Feet per Day
Mm
3
/d
Millions of Cubic Meters per Day
BBL/S Barrels per Second BBL/S Barrels per Second
BBL/M Barrels per Minute BBL/M Barrels per Minute
BBL/H Barrels per Hour BBL/H Barrels per Hour
BBL/D Barrels per Day BBL/D Barrels per Day
MBBL/D Millions of Barrels per Day MBBL/D Millions of Barrels per Day
Acre-inch/sec Acre-inches per second N/A
Acre-inch/min Acre-inches per minute N/A
Acre-inch/hr Acre-inches per hour N/A
Acre-inch/day Acre-inches per day N/A
Acre-foot/sec Acre-feet per second N/A
Acre-foot/min Acre-feet per minute N/A
Acre-foot/shr Acre-feet per hour N/A
Acre-foot/day Acre-feet per day N/A
