Chapter 1. Programming Site Data
36 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
Slot X Analog Outputs (cont.)
4. Use the [ and [ and [F1]-[F4] keys to specify the desired Output Measurement parameter, as shown in
Table 21.
The DIAG option provides access to a wide variety of diagnostics parameters. See Chapter 3, Diagnostics, of the
Service Manual for a complete description of these options.
Note: The measurement units that appear in these prompts are those selected in the GLOBL-SYSTM menu earlier
in this chapter.
5. Enter a value for the Base (low end) of the chosen output range and press [ENT].
6. Enter a value for the Full (high) end of the chosen output range and press [ENT].
7. Use the [F1]-[F4] keys to select the desired Error Option, the way the display responds during an error condition.
Available options are shown in Table 22.
8. Press [F1]-[F4] to set up another output or press [EXIT] to select another slot for set up.
For instructions on setting up additional inputs and/or outputs proceed to the appropriate section. Otherwise, press
[EXIT] twice to return to the Global Program prompt.
Table 21: Output Measurement Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[
 + [F1] = MDOT*
Mass Flow
[
 + [F2] = +MASS*
Forward Totalized Mass Flow
[
 + [F3] = -MASS*
Reverse Totalized Mass Flow
[
 + [F4] = POWER**
Energy Flow Power
[
 + [ + [F1] = +ENRG**
Forward Energy Flow
[
 + [ + [F2] = -ENRG**
Reverse Energy Flow
[
 + [ + [F3] = DIAG
Diagnostic
* Available only if Mass Flow (static)? = YES
**Available only if Energy Option = YES
Table 22: Error Response Options
Option Display Response
HOLD Holds the last “good” reading.
LOW Forces the outputs to the low setpoint.
HIGH Forces the outputs to the high setpoint.
OTHER Allows user to enter 4-20 mA error level in mA.
