Chapter 1. Programming Site Data
46 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
67 CH 1 TS-TR °F or °C 2 4 (32 bit integer)
69 CH 1 DELTH Btu/lb or J/gm 2 4 (32 bit integer)
71 CH 2 Power Power_u -- 4 (IEEE 32 bit)
73 CH 2 +Energy Energy_u Register 77 4 (32 bit integer)
75 CH 2 -Energy Energy_u Register 77 4 (32 bit integer)
77 CH 2 # Energy Digits none 0 2 (16 bit integer)
78 CH 2 TempS °F or °C 2 4 (32 bit integer)
80 CH 2 TempR °F or °C 2 4 (32 bit integer)
82 CH 2 TS-TR °F or °C 2 4 (32 bit integer)
84 CH 2 DELTH Btu/lb or J/gm 2 4 (32 bit integer)
86
5
Slot 1 Input A
4 (IEEE 32 bit)
88
5
Slot 1 Input B
4 (IEEE 32 bit)
90 Slot 2 Input A 4 (IEEE 32 bit)
92 Slot 2 Input B 4 (IEEE 32 bit)
94 Slot 3 Input A 4 (IEEE 32 bit)
96 Slot 3 Input B 4 (IEEE 32 bit)
98 Slot 4 Input A 4 (IEEE 32 bit)
100 Slot 4 Input B 4 (IEEE 32 bit)
102 Slot 5 Input A 4 (IEEE 32 bit)
104 Slot 5 Input B 4 (IEEE 32 bit)
106 Slot 6 Input A 4 (IEEE 32 bit)
108 Slot 6 Input B 4 (IEEE 32 bit)
508
6
MODBUS baud rate
none 0 2 (16 bit integer)
509
7
MODBUS parity
none 0 2 (16 bit integer)
510
8
MODBUS stop bits
none 0 2 (16 bit integer)
511 MODBUS meter addr none 0 2 (16 bit integer)
512 RESERVED none -- --
Table 26: DF868 2-Channel MODBUS Registers
MODBUS
Reg #
Description Units
Scaling
(decimal
places)
Size in Bytes
