Chapter 2. Displaying Data
56 DigitalFlow™ DF868 Multipurpose Ultrasonic Liquid Flowmeter Programming Manual (2-Channel)
2.2 The BIG Submenu (cont.)
Note: See Chapter 3, Operation, of the Startup Guide for more details on selecting a measurement parameter to
display.
DISPLAY FEATURES ‰
Press [F1] to select the BIG option. The measurement mode screen reappears
with the display in the BIG format.
DISPLAY FORMAT
previous selection appear here
BIG DUAL GRAPH LOG
site label site file ‰
Use the [F1]-[F4], [
 and [ keys to select the desired display parameter
option. Refer to Table 27 on page 56 for a complete description of the available
options.
Velocity Ft/s
6.95
(error codes appear here)
VEL VOLUM +TOTL -TOTL
Table 27: Measurement Parameter Options
Option Bar Choice Description
[F1] = VEL Flow Velocity
[F2] = VOLUM Volumetric Flow
[F3] = +TOTL Forward Totalized Volume Flow
[F4] = -TOTL Reverse Totalized Volume Flow
[
 + [F1] = TIME
Total Flow Measurement Time
[
 + [F2] = MDOT*
Mass Flow
[
 + [F3] = +MASS*
Forward Totalized Mass Flow
[
 + [F4] = -MASS*
Reverse Totalized Mass Flow
[
 + [ + [F1] = POWER**
Energy Flow Power
[
 + [ + [F2] = +ENRG**
Forward Energy Flow
[
 + [ + [F3] = -ENRG**
Reverse Energy Flow
[
 + [ + [F4] = DIAG
Diagnostic
* Available only if “Mass Flow (static)?” = YES
**Available only if “Energy Option” = YES
