Setting the pan, tilt, zoom, and focus
operation directions
You can set the direction that a remote camera moves in response to
the operation of the PAN/TILT lever, ZOOM button, and FOCUS dial
With this unit, you can set the direction for each camera number
Setting the panning direction
Set the operation of the remote camera in the horizontal direction in
response to the horizontal operation of the PAN/TILT lever
1 Press the MENU button
2 Open PAN DIRECTION menu [26]
3 Turn the F1 dial to display the camera number for which
to configure the setting
1.CAM1
NORMAL
4 Turn the F2 dial to select “NORMAL” or “REVERSE”,
and then press the F2 dial to confirm the selection
NORMAL : The remote camera moves to the left when the PAN/
TILT lever is moved toward the left, and to the right
when the lever is moved toward the right
REVERSE : Operation is in the opposite direction to NORMAL
Setting the tilting direction
Set the operation of the remote camera in the vertical direction in
response to forward and backward operation of the PAN/TILT lever
1 Press the MENU button
2 Open TILT DIRECTION menu [27]
3 Turn the F1 dial to display the camera number for which
to configure the setting
1.CAM1
NORMAL
4 Turn the F2 dial to select “NORMAL” or “REVERSE”,
and then press the F2 dial to confirm the selection
NORMAL : The remote camera moves upward when the PAN/TILT
lever is moved away from you, and downward when the
lever is moved toward you
REVERSE : Operation is in the opposite direction to NORMAL
Setting the zooming direction
Set the zooming operation of the lens in response to the operation of the
ZOOM button
1 Press the MENU button
2 Open ZOOM DIRECTION menu [28]
3 Turn the F1 dial to display the camera number for which
to configure the setting
1.CAM1
NORMAL
4 Turn the F2 dial to select “NORMAL” or “REVERSE”,
and then press the F2 dial to confirm the selection
NORMAL : The lens zooms toward the telephoto end when the
TELE side of the ZOOM button is pressed, and toward
the wide‑angle end when the WIDE side is pressed
REVERSE : Operation is in the opposite direction to NORMAL
