52
Table of setting items (dedicated dials and buttons)
Dial/button Setting item Remote camera Setting
(
*
1)
R/B GAIN dial R GAIN
B GAIN
AW‑HE120 –150 to +150
AW‑HE50
(
*
2)
, AW‑HE60 –30 to +30
AW‑HE2 “‑‑‑”
AW‑HE100 –30 to +30
AW‑HE870 –150 to +150
AW‑E860, AW‑E750, AW‑E650, AW‑E350 –150 to +150
AK‑HC1500, AK‑HC1800 –150 to +150
R/B PED dial R PED
B PED
AW‑HE120 –150 to +150
AW‑HE50, AW‑HE60 “‑‑‑”
AW‑HE2 “‑‑‑”
AW‑HE100 “‑‑‑”
AW‑HE870 –150 to +150
AW‑E860, AW‑E750, AW‑E650, AW‑E350 –150 to +150
AK‑HC1500, AK‑HC1800 –100 to +100
PED dial PED AW‑HE120 –150 to +150
AW‑HE50, AW‑HE60 –10 to +10
AW‑HE2 “‑‑‑”
AW‑HE100 –30 to +30
AW‑HE870 –150 to +150
AW‑E860, AW‑E750, AW‑E650, AW‑E350 –150 to +150
AK‑HC1500, AK‑HC1800 –150 to +150
GAIN button GAIN AW‑HE120 Auto, 0 dB to 18 dB (1 step)
AW‑HE50, AW‑HE60 Auto, 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB
AW‑HE2 “‑‑‑”
AW‑HE100 Auto, 0 dB to 12 dB (1 step), 15 dB, 18 dB
AW‑HE870 Auto, –6 dB to 18 dB (1 step)
AW‑E860, AW‑E750, AW‑E650 Auto, 0 dB to 30 dB, N/Eye L, N/Eye, N/Eye H
AW‑E350 Auto, 0 dB to 30 dB, N/Eye
AK‑HC1500, AK‑HC1800 LOW, MID, HIGH, SGAIN1, SGAIN2, SGAIN3
DETAIL button DETAIL AW‑HE2 “‑‑‑”
Other than AW‑HE2 Off, On
LEVEL AW‑HE120 Low, High
AW‑HE50, AW‑HE60 Low, High
AW‑HE2 “‑‑‑”
AW‑HE100 0 to 14
AW‑HE870 Low, High
AW‑E860, AW‑E750, AW‑E650, AW‑E350 Low, High
AK‑HC1500, AK‑HC1800 “‑‑‑”
(
*
1) “‑‑‑” indicates a setting that cannot be changed
(
*
2) AW‑HE50 without the AW‑HEF5HG/AW‑HEF5SG upgrade kit installed cannot operate R GAIN and B GAIN
Dial/button Setting item Remote camera Setting
(
*
1)
MEM SETTING button SPEED AW‑HE120, AW‑HE50, AW‑HE60 1 to 30
(
*
3)
AW‑HE2 “‑‑‑”
AW‑HE100, AW‑PH360, AW‑PH400,
AW‑PH405, AW‑PH650
1 to 30
(
*
3)
SCOPE AW‑HE120, AW‑HE50, AW‑HE60 MODE A, MODE B, MODE C
AW‑HE2 “‑‑‑”
AW‑HE100, AW‑PH360, AW‑PH400,
AW‑PH405, AW‑PH650
“‑‑‑”
(
*
3) This is indicated as “‑‑‑” in TMEM mode and cannot be set
