Configuring the unit operation settings
Enabling or disabling operation with the ENABLE buttons
The unit has five ENABLE buttons
Each of the ENABLE buttons can be used to independently enable or disable the corresponding operation shown below
USER ENABLE button
Operation of USER buttons
MEM ENABLE button
Operation of memory (preset memory and tracing memory)
Color adjustment ENABLE button
Operation of color adjustment section
PAN/TILT ENABLE button
Operation of PAN/TILT lever
FOCUS/ZOOM/IRIS ENABLE button
Operation of FOCUS dial, ZOOM button, and IRIS dial
1 Press the ENABLE button
The button indicator lighting state changes
Button indicator on or blinking : Operation of the corresponding functions are enabled
Button indicator off : Operation of the corresponding functions are disabled
Menu operation is possible even when the MEM ENABLE button indicator is off
The PAN/TILT ENABLE button indicator blinks while the PAN/TILT lever is being used to operate the switcher
⇒ “Operating the switcher with the PAN/TILT lever and ZOOM button” (page 34)
The FOCUS/ZOOM/IRIS ENABLE button indicator blinks while the ZOOM button is being used to operate the switcher
⇒ “Operating the switcher with the PAN/TILT lever and ZOOM button” (page 34)
When the operation of the ENABLE buttons is disabled by menu operation, operating the ENABLE buttons has no effect
⇒ “Enabling or disabling operation of the ENABLE buttons by menu operation” (page 28)
