Operations of AW‑HE2
AW‑HE2 HD integrated cameras can be operated from the unit
This section describes the operations which are different from the
corresponding operations of other remote cameras
 The method for connecting AW‑HE2 and the unit is the same
as that for connecting AW‑HE2 and AW‑RP50 Refer to the
Operating Instructions for the AW‑HE2
Note
<Invalid operations>
Color adjustment
section
R/B GAIN dial, R/B PED dial, PED dial, GAIN
button, DETAIL button, AUTO GAIN button, ABB
button
Focus, zoom and
iris section
FOCUS dial, Auto focus button, One‑touch auto
focus button, FOCUS SPEED dial
User button
section
SCENE 1 to SCENE 4 buttons
(
*
)
(
*
) Even if you press these buttons while the SHIFT button indicator is
on, the operations will have no effect
(The shooting mode cannot be selected)
<Indications which are different>
IRIS indicator Display is not updated during auto iris use
ZOOM indicator
FOCUS indicator
All indicators are off
<Operations which are different>
PAN/TILT lever When the zoom position is the WIDE end
side, the output images do not change even if
the lever is operated
Preset memory  The preset numbers that can be registered
and recalled are PMEM 1 to PMEM 9
(page number: Page 1)
 PRESET SCOPE and PRESET SPEED
cannot be set
Tracing memory The start position cannot be stored in
TMEM10
SD card SAVE and LOAD of the CAM item cannot be
executed
USER buttons If the following settings are assigned, PinP
display of AW‑HE2 can be operated with the
USER buttons
CAM_PINP DISP:
Displays or hides PinP
Each press of the button switches in the
order of display PinP → hide PinP →
display PinP, and so on
CAM_PINP CTL:
Switches the control target (control mode)
of the PAN/TILT lever and ZOOM button
Each press of the button switches in the
order of PinP → main screen → PinP, and
so on
CAM_PINP POS:
Changes the display position of PinP
Each press of the button switches in the
order of top right → bottom right → bottom
left → top left → top right, and so on
 For the PinP display function of AW‑HE2, refer to the Operating
Instructions for the AW‑HE2
<Invalid menu operations>
Menu Setting item
SHUTTER [21] 1 SHUTTER
2 SPEED
ND FILTER [22] 1 ND FILTER
PTZ ADJUST [30] 2 SPEED WITH Z
3 LIMIT UP
4 LIMIT DOWN
5 LIMIT LEFT
6 LIMIT RIGHT
